DR Series RGB CW Dimmable
Product advantage
- Optional power, 100W~250W
- RGB/Cool white/Warm White colors can be selected
- Efficient and energy-saving, with an efficiency of over 92%
- lEEE1789 No Flash High FrequencyExemption Level
- Voltage range input200-240V PF>0.9
- Working environment temperature range:-25”C-45 "C
- Certification: CE, UKCA, ENEC, CB, TUV RCM,CCC
- A fully formed plastic shell, the product meets the structural requirements of Class ll power supply
- Supportfor Zigbee, WiFi, Wireless, infrared remote control
- Dimming depth 0.1%, dimming range 1% -100%
- it has multiple protecion functions such a output overoad, short circuit overvoltage, and overheating, and can automaticaly recover after fault resolution
Specifications
●Rated input voltage: 200-240VAC
●Limited voltage: 180-264VAC
●Protection type: Class Ⅱ
● Output type: SELV
● Output voltage accuracy: 5%
●Power on time: <0.5s
●THD: <20%
●Surge: L-N:2KV
●withstand voltage：I/P-O/P:3750Vac, I/P O/P-DIM:1750Vac
●Flicker-free: Pst LM <1,SVM <0.4
●Life time: Normal 50,000 hours
●Warranty: 3 years
