CGseries80% Power-Isolated Cabinet Power Supply
Product advantages
- Optional power 60w~350W
- Efficient and energy-saving, with an efficiency of up to 93%
- Voltage range input 200-240V, PF>0.5
- Working environment temperature range: -25 °C-50°C
- Comply with CCC industrial standards
- Aluminum alloy shell, product meets Classl power supply structure requirements
- Safe and reliable, withstand voltage 3.75KV, lightning surge 2KV
8.ithas multiple protection fundtionssuch as output overload, short circuit, overvotage,and overheating, and can automaticaly recover after fault resolution
Specifications
- Rated input voltage:200-240VAC
- Limited voltage: 180-264VAC
- Protection type: Class I
- Output type: SELV
- Output voltage accuracy: 3%e
- Power on time: <0.5s
- Surge: L-N:2KV, L-FG/N-FG:2KV
- withstand voltage: l/P-0/P:3.75KVac, I/P O/P-FG:1.5KVace
- Life time: Normal 50,000 hourse
- Warranty: 3 years
